Klinger Top-Chem-2003 Gasket
Applications
General industry / Chemical / Oil & Gas / Energy / Infrastructure / Pulp & Paper / Marine / Automotive / Food & Beverage / Pharma
Product Description
Features
KLINGER top-chem-2003, consisting of PTFE filled with hollow glass-microspheres, this gasket material provides high adaptability and tightness even at low surface loads.
Its chemical properties make it the ideal choice for strongly acidic and alkaline applications as well as for medium temperatures and loads.
Benefits
Excellent sealing at low stress.
Superior chemical resistance.
Conforms easily.
No ageing of the material.
Specification
| Composition | PTFE filled with hollow glass-microspheres. |
| Pressure | 0 to 200 bar |
| Temperature | -200℃ to 250℃ |
| Sheet dimensions | Sizes: 1500 x 1500 mm Thicknesses: 1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm |
| Approvals | Oxygen-tested DIN-DVGW DVGW H2-ready (ZP 5123) DIN 16421 (W 270) KTW-BWGL DNV approval TA-Luft (Clean air) FDA conformity (components of KLINGER®topchem 2003 comply with the FDA requirements) Regulation (EU) No. 1935/2004 (incl. 10/2011) VDI 2200 blowout |
